Cessna Citation Sovereign
Designed for long-distance flights, the Cessna Citation Sovereign offers a combination of maximum speed, comfort, and range.
9 PAXPassengers
approx.
approx.
1.74 mCabin Height
approx.
approx.
3.82 cu mBaggage Volume
(max)
(max)
5408 kmRange
depending on weight and weather
depending on weight and weather
Cessna Citation Sovereign
Specifications
Manufacturer
Manufacturer | Cessna |
Production Years | 2004 - 2013 |
Powerplant
Engine Manufacturer | Pratt & Whitney Canada |
Engine Model | PW306C |
Engine Quantity | 2 Engines |
Thrust | 2617 kg |
Exterior
Wingspan | 19.29 m |
Fuselage | 19.35 m |
Interior
Number of Passengers (Pax) | 9 Passengers |
Cabin Width | 1.68 m |
Cabin Length | 7.70 m |
Cabin Height | 1.74 m |
Total Cabin Volume | 16.17 cu m |
Total Baggage Volume | 3.82 cu m |
Speed
Normal Cruise Speed | 850 kph |
Long-Range Cruise Speed | 719 kph |
Maximum Cruise Speed | 850 kph |
Range Map
Optimum Cruise Range | 5408 km |
Maximum Cruise Range | 5223 km |
Seats Full Range | 4852 km |
Ferry Range | 5575 km |
Weight
Ramp Weight | 13857 kg |
Max Gross Takeoff Weight | 13744 kg |
Azami İniş Ağırlığı | 12293 kg |
Max Landing Weight | 5625 kg |
Usable Fuel Weight | 5091 kg |
Powerplant
Engine Manufacturer | Pratt & Whitney Canada |
Engine Model | PW306C |
Engine Quantity | 2 Engines |
Thrust | 5770 lb |
Exterior
Wingspan | 63.3 ft |
Fuselage | 63.5 ft |
Interior
Number of Passengers (Pax) | 9 Yolcu |
Cabin Width | 5.5 ft |
Cabin Length | 25.25 ft |
Cabin Height | 5.7 ft |
Total Cabin Volume | 571 cu ft |
Total Baggage Volume | 135 cu ft |
Speed
Normal Cruise Range | 459 kts |
Long-Range Cruise Speed | 388 kts |
Maximum Cruise Speed | 459 kts |
Range Map
Optimum Cruise Range | 2920 nm |
Maximum Cruise Range | 2820 nm |
Seats Full Range | 2620 nm |
Ferry Range | 3010 nm |
Weight
Ramp Weight | 30550 lb |
Max Gross Takeoff Weight | 30300 lb |
Max Landing Weight | 27100 lb |
Usaful Fuel Weight | 12400 lb |
Usable Fuel Weight | 11223 lb |
Cabin Layout
Suggested posts may change from time to time. You can get more details about Cessna Citation Sovereign from Mira Aviation Experts.
