Gulfstream G IV
Designed for long-distance flights, the Gulfstream G IV offers a combination of maximum speed, comfort, and range.
13 PAXPassengers
approx.
approx.
1.89 mCabin Height
approx.
approx.
4.79 cu mBaggage Volume
(max)
(max)
7719 kmRange
depending on weight and weather
depending on weight and weather
Gulfstream G IV
Specifications
Manufacturer
| Manufacturer | Gulfstream |
| Production Years | 1985 - 1992 |
Powerplant
| Engine Manufacturer | Rolls Royce |
| Engine Model | TAY 611-8 |
| Engine Quantity | 2 Engines |
| Thrust | 6282 kg |
Exterior
| Wingspan | 23.71 m |
| Fuselage | 26.91 m |
Interior
| Number of Passengers (Pax) | 13 Passengers |
| Cabin Width | 2.23 m |
| Cabin Length | 13.75 m |
| Cabin Height | 1.89 m |
| Total Cabin Volume | 46.95 cu m |
| Total Baggage Volume | 4.79 cu m |
Speed
| Normal Cruise Speed | 882 kph |
| Long-Range Cruise Speed | 824 kph |
| Maximum Cruise Speed | 926 kph |
Range Map
| Optimum Cruise Range | 7719 km |
| Maximum Cruise Range | 6871 km |
| Seats Full Range | 7038 km |
| Ferry Range | 7778 km |
Weight
| Ramp Weight | 33385 kg |
| Max Gross Takeoff Weight | 33204 kg |
| Azami İniş Ağırlığı | 26536 kg |
| Max Landing Weight | 13835 kg |
| Usable Fuel Weight | 13281 kg |
Powerplant
| Engine Manufacturer | Rolls Royce |
| Engine Model | TAY 611-8 |
| Engine Quantity | 2 Engines |
| Thrust | 13850 lb |
Exterior
| Wingspan | 77.8 ft |
| Fuselage | 88.3 ft |
Interior
| Number of Passengers (Pax) | 13 Yolcu |
| Cabin Width | 7.3 ft |
| Cabin Length | 45.1 ft |
| Cabin Height | 6.2 ft |
| Total Cabin Volume | 1658 cu ft |
| Total Baggage Volume | 169 cu ft |
Speed
| Normal Cruise Range | 476 kts |
| Long-Range Cruise Speed | 445 kts |
| Maximum Cruise Speed | 500 kts |
Range Map
| Optimum Cruise Range | 4168 nm |
| Maximum Cruise Range | 3710 nm |
| Seats Full Range | 3800 nm |
| Ferry Range | 4200 nm |
Weight
| Ramp Weight | 73600 lb |
| Max Gross Takeoff Weight | 73200 lb |
| Max Landing Weight | 58500 lb |
| Usaful Fuel Weight | 30500 lb |
| Usable Fuel Weight | 29280 lb |
Cabin Layout
