Gulfstream G500
Designed for intercontinental flights, Gulfstream G500 offers a luxurious flight experience with a combination of high comfort, performance, and range.
13 PAXPassengers
approx.
approx.
1.92 mCabin Height
approx.
approx.
13.03 cu mBaggage Volume
(max)
(max)
10010 kmRange
depending on weight and weather
depending on weight and weather
Gulfstream G500
Specifications
Manufacturer
| Manufacturer | Gulfstream |
| Production Years | 2018 - Present |
Powerplant
| Engine Manufacturer | Pratt & Whitney Canada |
| Engine Model | PW814GA |
| Engine Quantity | 2 Engines |
| Thrust | 6869 kg |
Exterior
| Wingspan | 26.33 m |
| Fuselage | 27.79 m |
Interior
| Number of Passengers (Pax) | 13 Passengers |
| Cabin Width | 2.41 m |
| Cabin Length | 14.50 m |
| Cabin Height | 1.92 m |
| Total Cabin Volume | 48.56 cu m |
| Total Baggage Volume | 13.03 cu m |
Speed
| Normal Cruise Speed | 924 kph |
| Long-Range Cruise Speed | 904 kph |
| Maximum Cruise Speed | 956 kph |
Range Map
| Optimum Cruise Range | 10010 km |
| Maximum Cruise Range | 8473 km |
| Seats Full Range | 9384 km |
| Ferry Range | 10140 km |
Weight
| Ramp Weight | 36288 kg |
| Max Gross Takeoff Weight | 36107 kg |
| Azami İniş Ağırlığı | 29189 kg |
| Max Landing Weight | 15037 kg |
| Usable Fuel Weight | 13721 kg |
Powerplant
| Engine Manufacturer | Pratt & Whitney Canada |
| Engine Model | PW814GA |
| Engine Quantity | 2 Engines |
| Thrust | 15144 lb |
Exterior
| Wingspan | 86.4 ft |
| Fuselage | 91.16 ft |
Interior
| Number of Passengers (Pax) | 13 Yolcu |
| Cabin Width | 7.9 ft |
| Cabin Length | 47.58 ft |
| Cabin Height | 6.3 ft |
| Total Cabin Volume | 1715 cu ft |
| Total Baggage Volume | 460 cu ft |
Speed
| Normal Cruise Range | 499 kts |
| Long-Range Cruise Speed | 488 kts |
| Maximum Cruise Speed | 516 kts |
Range Map
| Optimum Cruise Range | 5405 nm |
| Maximum Cruise Range | 4575 nm |
| Seats Full Range | 5067 nm |
| Ferry Range | 5475 nm |
Weight
| Ramp Weight | 80000 lb |
| Max Gross Takeoff Weight | 79600 lb |
| Max Landing Weight | 64350 lb |
| Usaful Fuel Weight | 33150 lb |
| Usable Fuel Weight | 30250 lb |
Cabin Layout
