IAI Astra SP
Designed for long-distance flights, the IAI Astra SP offers a combination of maximum speed, comfort, and range.
7 PAXPassengers
approx.
approx.
1.71 mCabin Height
approx.
approx.
1.81 cu mBaggage Volume
(max)
(max)
4897 kmRange
depending on weight and weather
depending on weight and weather
IAI Astra SP
Specifications
Manufacturer
Manufacturer | IAI |
Production Years | 1990 - 1995 |
Powerplant
Engine Manufacturer | Honeywell Engines |
Engine Model | TFE 731-3C |
Engine Quantity | 2 Engines |
Thrust | 1678 kg |
Exterior
Wingspan | 16.03 m |
Fuselage | 16.92 m |
Interior
Number of Passengers (Pax) | 7 Passengers |
Cabin Width | 1.45 m |
Cabin Length | 5.21 m |
Cabin Height | 1.71 m |
Total Cabin Volume | 8.61 cu m |
Total Baggage Volume | 1.81 cu m |
Speed
Normal Cruise Speed | 830 kph |
Long-Range Cruise Speed | 767 kph |
Maximum Cruise Speed | 852 kph |
Range Map
Optimum Cruise Range | 4897 km |
Maximum Cruise Range | 4593 km |
Seats Full Range | 4315 km |
Ferry Range | 5149 km |
Weight
Ramp Weight | 11249 kg |
Max Gross Takeoff Weight | 11181 kg |
Azami İniş Ağırlığı | 9390 kg |
Max Landing Weight | 5171 kg |
Usable Fuel Weight | 4239 kg |
Powerplant
Engine Manufacturer | Honeywell Engines |
Engine Model | TFE 731-3C |
Engine Quantity | 2 Engines |
Thrust | 3700 lb |
Exterior
Wingspan | 52.6 ft |
Fuselage | 55.5 ft |
Interior
Number of Passengers (Pax) | 7 Yolcu |
Cabin Width | 4.75 ft |
Cabin Length | 17.1 ft |
Cabin Height | 5.6 ft |
Total Cabin Volume | 304 cu ft |
Total Baggage Volume | 64 cu ft |
Speed
Normal Cruise Range | 448 kts |
Long-Range Cruise Speed | 414 kts |
Maximum Cruise Speed | 460 kts |
Range Map
Optimum Cruise Range | 2644 nm |
Maximum Cruise Range | 2480 nm |
Seats Full Range | 2330 nm |
Ferry Range | 2780 nm |
Weight
Ramp Weight | 24800 lb |
Max Gross Takeoff Weight | 24650 lb |
Max Landing Weight | 20700 lb |
Usaful Fuel Weight | 11400 lb |
Usable Fuel Weight | 9345 lb |
Cabin Layout
IAI Astra SP
Range Map
IAI Astra SP range maps will be here very shortly.For detailed information about IAI Astra SP, please contact us.
Suggested posts may change from time to time. You can get more details about IAI Astra SP from Mira Aviation Experts.
